Zn/Al Metallized Bopp Capacitor Film

Contact Now* Send an Inquiry to this supplier.
or
Start Order * Name your price

Browse by Category

Contact us

AnHui Safe Electronics Co., LTD.
[China]

Address
NO.1771 QiFeng Road, Shizishan EConomic Development Zone. Tongling Anhui
Phone
86-1895622-9826
Contact name
Mia

Quick Information

  • Brand Name: SF
  • Place of Origin: China
  • Model Number : Metallized Film For capacitor use
  • Width : 4.5-130mm
  • Thickness : 1.6-12um
  • Margin Value : 0.5mm 1.0mm 1.5mm 2.0mm 2.5mm
  • Specification : Metallized Film For Capacitors
  • Types Of Metallized Layer : Zn/Al Metallized Film
  • Density : 0.905+/-0.005g/cm3
  • Processing Type : Vacuum Coating Capacitor Film
  • Packaging Details : vaccum-sealed metallized plastic bags
  • Transport Package : Vaccum Package For Standard Export Carton

Description

Product Information

Mpp Film TypeMetallized Polypropylene Film For Capacitors
Width4.5-130mm
Thickness1.6-12um
Margin Value0.5mm 1.0mm 1.5mm 2.0mm 2.5mm
SpecificationMetallized Film For Capacitors
Types Of Metallized LayerAl Metallized Film、Zn/Al Metallized Film
Density0.905+/-0.005g/cm3
Processing TypeVacuum Coating Capacitor Film
Trade MarkCSF
MOQ1 Kilogram



MPP Film Structure Chart



Products Types

1. Single margin Opp film with one side Zn-Al metallized

2. Single margin Opp film with slope resistance one side Zn-Al metallized

3. Single margin Opp film with high resistance one side Zn-Al metallized

4. Segmented metallized film

5. Middle margin PET film with double sided Al metallized

6. Single margin OPP film with one side Al metallized

7. Double margin OPP film with one side Al metallized

8. Multi-margin OPP film with one side Zn-Al metallized

Note: We can design and produce all kinds of metallized film for capacitors according to customer's requirement.


Cores

1. Material:Plastic

2. Width:Film Slit Width ±0.3mm

3. Inner Diameter:75mm +1.0mm/-0.5mm


Outer Diameter of film roll

Slit widths Recommend outer diameter
4.5mm≤W<10mm 140mm≤D≤185mm
10mm≤W<25mm 150mm≤D≤185mm
25mm≤W<50mm 150mm≤D≤240mm
50mm≤W 150mm≤D≤350mm


Parameters Of MPP Film


Parameters Of MPET Film


Packing

1. Film rolls are packed and heat-sealed in vacuum plastic bags with desiccants inside

2. The bags are marked with type labels

3. The bags are packed in carton cases

4. The cartons are wrapped in wooden cases or reinforced carton


Storage

1. Metallized film should be stored in its original package with temperature 5~35ºC and humidity less than 85%RH before using.

2.Metallized layer is easily oxidized when exposure to moisture.Therefore,the film should

be used as soon as possible when opened.

3. The recommended temperature is 15-25ºC with humidty less than 60%RH after opening.

4. With original sealed package,and stored as mentioned above,the storage time can be as following:

Al metallized film:12 months from the delivery date.Al/Zn Alloy metallized film :As zinc is

quite unstable,the storage period(from delivery date) depends on the resistance of the film:

≦10Ω:6 months

10-30Ω:3 months

>30Ω:1 month



Production Equipments


Certification and invention patent




Strong R&D Strength


Enterprise honor



Team Activities


Contact Information

Company Anhui Safe Electronics CO.,LTD.
Address NO.1771 QiFeng Road,Shizishan National High Technology Zone,Tongling,Anhui, China
Tel 0086 - 562 - 2821018
Fax 0086 - 562 - 2821558
Mobile/Whatsapp 0086 - 13305620368 (Helen)
Homepage www.film-capacitor.com


Price

  • Delivery Port : Shanghai

Packaging & Delivery

  • Packing :VaccumPackageForStandardExportCarton
  • Packaging Size : 604 x 308 x 150  Millimeters
  • Package Weight : 12
  • Delivery Lead Time : 7~15 Days After Payment
  • Supply Ability : 200 Tons Per Month

Product Image

  • 1Zn/Al Metallized Bopp Capacitor Film image 1
  • 2 Zn/Al Metallized Bopp Capacitor Film image 2
  • 3 Zn/Al Metallized Bopp Capacitor Film image 3
  • 4 Zn/Al Metallized Bopp Capacitor Film image 4
